• H.265/H.264 dual stream decoding, embedded Linux operating system
• Support synchronous recording, remote monitoring, backup; up to 16CH video synchronous playback and multi-channel backward playback
• Support 30min instant playback, 30s pre-record
• Standard ONVIF, SLINK, RTSP protocol
• Support DDNS, EMAIL, UPNP, NTP, P2P and other functions
• Support IE, mobile phone APP, VMS monitoring
• Support external alarm; Two-way audio intercom
• Support our Smart IPC: Target Count, Electric Fence, Humaniod Detection, Retrograde Detection, Leave Position Detection
• Support IPC centralized management, including IPC parameter configuration, information export and import, real-time information acquisition and upgrade, etc.
• Support channel grouping, preview tour
• Support disk grouping quotas and disk group storage modes
• Support double password authentication
• Support network monitoring: network traffic, network delay packet loss test, network packet capture backup
• Support current bandwidth, stream information
• Support offline collection
|
System
|
|
Main Chipset
|
Mstar SSR621Q
|
|
Operating System
|
Embedded Linux
|
|
Bandwidth
|
40M
|
|
Video Format
|
H.265
|
|
Video Resolution
|
5MP\3MP\2MP
|
|
Smart Functions
|
Target Count, Electric Fence, Humaniod Detection, Retrograde Detection, Leave Position Detection (need front end IPC supported)
|
|
Record Mode
|
Manual, Schedule, Motion Detection, Timing, Alarm, Stop
|
|
Playback
|
4CH 1080P, 1CH 5MP
|
|
Backup Mode
|
USB Device/Network
|
|
Video, Audio, Alarm
|
|
Video Input
|
4CH Digital (2592X1944) + 4CH Preview + 4CH Playback
|
|
Video Output
|
1 HDMI, 1 VGA
|
|
Audio Input & Output
|
HDMI audio
|
|
Alarm Input & Output
|
N/A
|
|
Storage
|
|
HDD
|
1 SATA, MAX 8TB HDD
|
|
E-Sata
|
N/A
|
|
Network
|
|
Network Interface
|
1*RJ45 10M/100M self-adaptive LAN port
|
|
POE
|
4CH, 10/100Mbps self-adaptive Ethernet port, IEEE802.3af, 13W
|
|
Network Function
|
DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P
|
|
Smart Phone
|
iPhone, Android
|
|
External Ports
|
|
USB
|
2 USB Ports(2 USB2.0)
|
|
RS232
|
N/A
|
|
RS485
|
N/A
|
|
Others
|
|
Power Supply
|
DC52V 1.5A
|
|
Power Consumption
|
≤10W(without HDD )
|
|
Dimension
|
Equipment: 450X240X70mm, Packing: 290X70X300mm
|
|
Weight
|
N.W.: 1Kg; With Package: 1.4Kg
|
|
Outside Carton
|
10 pcs/Carton. 595mm×368mm×325mm; Weight: 14.3Kg
|
