NVR
|
|
Model
|
TT-21A18FK-N
|
|
Operation System
|
H.265 Embedded Linux Operation System
|
|
IP Video Input
|
8 CH x 1080P NVR,RJ45 Network Interface
|
|
HDMI Output
|
1 CH，HDMI ;Max Resolution:1920x1080P;
|
|
Video Compression
|
H.265
|
|
Recording /Playback
|
8 CH 1.0MP Recording & 4CH Playback
|
|
8 CH 1.3MP Recording & 4CH Playback
|
|
8 CH 2.0MP Recording & 4CH Playback@15fps
|
|
Video Resolution
|
2.0MP Recording
|
|
Network Port
|
1 *RJ45 10M/100Madaptive ethernet port
|
|
Internet Protocol
|
UPnP ,SMTP ,PPoE ,DHCP
|
|
Storage Type
|
1 * SATA Interface
|
|
Audio
|
Option
|
|
Storage Capacity
|
6TB In Max
|
|
Backup*Smart function
|
USB Backup ，Internet Backup
|
|
USB Interface
|
1 * USB2.0 Interface(Support Upgrade,Backup,Mouse)
|
|
Work Temperature
|
-10°---- 55°
|
|
Size
|
215mmx235mmx55mm
|
|
Device Control
|
Remote Control & Mouse
|
|
Power Input
|
DC +12 V / 2A
|
|
Power Consumption
|
≤6W
|
|
Weight
|
1.86kg
|
|
WIFI IPC Camera
|
|
Model
|
TT-21A18FK-C
|
|
Image Sensor
|
1/3” Progressive Scan Sensor/AK3918E+SC2232
|
|
Lens
|
3.6mm (6mm Option)
|
|
S/N Ratio
|
> 39.1 dB
|
|
Video compress standard
|
Standard H.265,
|
|
Stream parameter
|
Dual stream,1920x1080@15fps,640x480@15fps
|
|
Resolution
|
1920*1080P
|
|
Minimum Illumination
|
Color: 0.1Lux,B/W: 0.01Lux
|
|
OSD
|
Date Time & Title
|
|
Audio
|
Option
|
|
White Balance
|
Auto
|
|
Day&Night
|
IR cut filter with auto switch
|
|
3D-DNR
|
Auto
|
|
Thunder Prevention
|
Standard IEC61000-4-5
|
|
IR LED
|
3pcs LED; IR CUT dual filter auto switch
|
|
IR distance
|
15m-20m
|
|
IP Waterproof Level
|
IP66
|
|
Power Consumption
|
≤3W
|
|
Operation Temperature/Humidity
|
-10℃ to +50℃ / 30% to 80% RH
|
|
Storage Temperature/Humidity
|
-20℃ to +60℃ / 20% to 90% RH
|
|
Power
|
DC12V/1A
|
|
Weight
|
0.3kg
|
