1.36PCS IR F5 LED 30Meter;
2.Varifocal 2.8-12mm Lens;
3.Support 1080P,3.0MP,4.0MP,5.0MP;
4.Waterproof :IP66
5.CMOS Sensor;
6.Support IR-CUT;
|
Model No.
|
HD60F3G
|
HD60F3G
|
HD60F3SA
|
HD60F3
|
HD60F3SD
|
HD60F3NL
|
HD60F3SL
|
|
Camera
|
|
Image Sensor
|
GC2023
|
GC2023
|
SONY IMX323
|
SONY IMX323
|
SONY IMX307
|
SONY IMX291
|
SONY IMX290
|
|
Main processor
|
FH8536
|
FH8536
|
FH8536
|
NVP 2441H
|
NVP 2441H
|
NVP 2441H
|
FH8550D
|
|
Resolution
|
1080P
|
|
Effective Pixels
|
1920* 1080P
|
|
Pixels
|
2.0 Mega Pixel
|
|
Frame rate
|
25fps@PAL / 30fps@ NTSC
|
|
TV System
|
PAL/NTSC
|
|
Electronic Shutter Time
|
Auto: PAL 1/25s~1/50,000s; NTSC 1/30s~1/60,000s
|
|
Sync System
|
Internal
|
|
Usable Illumination
|
0.01Lux
|
STARVIS 0.0001Lux
|
|
S/N Ratio
|
≥52dB
|
|
Scanning System
|
Progressive
|
|
Hybird Type
|
AHD/TVI/CVI/CVBS (960H) 4 in 1
|
|
Lens
|
|
Focus Length
|
2.8-12mm Manual Zoom
|
|
Focus Control
|
Manual Zoom
|
|
Lens Type
|
Varifocal
|
|
Night Vision
|
|
Infrared LED
|
12μ x 36PCS
|
|
Infrared Distance
|
30M
|
|
IR Status
|
Under 10 Lux By CDS
|
|
IR Power On
|
CDS Auto Control
|
|
Camera Features
|
|
OSD/UTC Menu Language
|
EN, CN, DE, FRA, IT, ES, PL, RU, PT, NL, TR
|
|
Day/Night
|
Color/ B&W (IR-CUT )
|
|
White Balance
|
Auto/Manual
|
|
Gain Control
|
Auto
|
|
Noise Reduction
|
2D/ 3D NR
|
|
Picture Adjustment
|
YES
|
|
OSD Support
|
YES
|
|
General
|
|
Housing
|
Metal
|
|
Waterproof
|
YES, IP66 Waterproof
|
|
Bracket
|
NO
|
|
IR Cut Filter
|
YES
|
|
Operation Temperature
|
-10℃ ~ +50℃ RH95% Max
|
|
Storage Temperature
|
-20℃ ~ +60℃ RH95% Max
|
|
Power Source
|
DC12V±10%,500mA
|
|
Dimension
|
131*93mm
|
|
Weight
|
0.9KG
|
